| Category | Parameter | Value |
| Grid | Max AC input current (A) | 3x63 |
| Rated AC voltage (V) | 3/N/PE~400/230 | |
| Rated AC frequency (Hz) | 50/60 | |
| EPS | Max EPS input current (A) | 3x63 |
| Rated EPS voltage (V) | 3/N/PE~400/230 | |
| Rated EPS frequency (Hz) | 50/60 | |
| Load | Rated output current (A), on grid mode | 3x63 |
| Rated output current (A), EPS mode | 3x63 | |
| Rated grid voltage (V) | 3/N/PE~400/230 | |
| Rated grid frequency (Hz) | 50/60 | |
| General Data | Operating Temperature (掳C) | -20~+60 |
| Switch Time (s) | 0.5 | |
| Dimension (mm) | 300x220x170 | |
| Weight (kg) | 4.85 |
