Microinverter
X1-Micro 2 in 1 G2
-
800 W / 1000 W / 1200 W
This high-performance microinverter features a plug-and-play design with built-in WiFi/PLC communication and AC coupling support. Designed for maximum compatibility, it enables the integration of 1-phase microinverters into a 3-phase grid.
Product Advantage
Delivering up to 1200 VA output and 18 A DC input, the system offers dual MPPT tracking and up to 97% efficiency. Built-in safety features—including rapid shutdown, protection relay, and IP67-rated enclosure—provide robust protection in diverse environments.
High Efficiency
Max. 1200 VA output power
Max. 18 A DC input current
Two MPPT channels
Max. efficiency up to 97%
Intelligent Design
Reactive power regulation (0.8 leading..0.8 lagging)
Built-in WiFi communication
Support zero export function
Module level monitoring and control
Remote firmware upgrades, parameter configuration, and fault analysis
Assured Safety
Rapid shutdown function
Safety protection relay integrated
IP67 ingress protection
Flexible Adaptability
Plug and play
Supporting AC coupling solution
Supporting 1-phase microinverter integration into 3-phase power grid
Product Parameters
-
X1-Micro 1200 G2-
PV INPUT
Commonly used module power per input 400~670+ W MPPT voltage range 22-60 V Number of MPP. trackers/strings per MPPT 2 / 1 -
AC OUTPUT
Rated AC output power 1200 VA -
EFFICIENCY
Max. efficiency 97.00% MPPT efficiency 99.90% -
GENERAL
Ingress protection rating IP67 Dimensions (W /H / D) 234x191 x41 mm Weight 3.3 kg Cooling Concept Natural cooling
-
-
X1-Micro 1000 G2
-
PV INPUT
Commonly used module power per input 400~670+W MPPT voltage range 22-60 V Number of MPP. trackers/strings per MPPT 2 / 1 -
AC OUTPUT
Rated AC output power 1000 VA -
EFFICIENCY
Max. efficiency 97.00% MPPT efficiency 99.90% -
GENERAL
Ingress protection rating IP67 Dimensions (W /H / D) 234x191 x41 mm Weight 3.3 kg Cooling Concept Natural cooling
-
-
X1-Micro 800 G2
-
PV INPUT
Commonly used module power per input 320~540+W MPPT voltage range 22-60 V Number of MPP. trackers/strings per MPPT 2 / 1 -
AC OUTPUT
Rated AC output power 800 VA -
EFFICIENCY
Max. efficiency 97.00% MPPT efficiency 99.90% -
GENERAL
Ingress protection rating IP67 Dimensions (W /H / D) 234x191 x41 mm Weight 3.3 kg Cooling Concept Natural cooling
-
