Residential ESS

X-MS 2000

  • All-In-One Balcony ESS

This all-in-one balcony energy storage system offers a powerful, plug-and-play solution designed for micro home energy solution. With up to 2400W solar input across 4 MPPTs and scalable battery capacity expandable to 11.98kWh, it combines ultra-fast installation, reliable off-grid capability, and intelligent energy management.

Product Advantage

This all-in-one balcony energy storage system offers a powerful, plug-and-play solution designed for micro home energy solution. With up to 2400W solar input across 4 MPPTs and scalable battery capacity expandable to 11.98kWh, it combines ultra-fast installation, reliable off-grid capability, and intelligent energy management.

Power & Performance

  • Up to 2400W solar input with 4 MPPTs

  • Max charging power 3400W, 1000W bidirectional AC power

  • UPS-level switchover time <10ms

  • Long-lasting power with 6000 charge cycles

System Design & Installation

  • All-in-one compact design, plug-and-play installation

  • DIY expansion to 11.52 kWh capacity

Environmental Resilience

  • IP65 ingress protection

  • Built-in battery heating function, reliable performance in extreme temperature (-20°C)


Efficiency & Sustainability

  • Zero waste with self-consumption

  • Support TOU mode to maximize family benefits

Product Parameters

  • X-MS 2000
  • X-MS 2000
    • PV INPUT

      Max. PV input power

      2400 W

      Max. PV input voltage

      60 V

      Operation voltage range

      16 ~ 60 V

      No. of MPP trackers

      4



    • AC ON-GRID

      Rated Input / output apparent power

      800 VA

      * It can be customized by using the Solax App and can be adjusted up to 1000 VA

      Rated AC output voltage

      220 V / 230 V / 240 V


    • BATTERY DATA

      Battery type

      LFP

      Max. discharging current

      100 A


    • GENERAL
      Ingress protectionIP65

      Dimensions (W x H x D)

      460 x 240 x 240 mm

      Net Weight

      24 kg


    • STANDARD

      Safety

      IEC62109-1 / -2

      EMCIEC62619, UN38.3, IEC / EN 61000-6-1, IEC / EN 61000-6-2, IEC / EN 61000-6-3, IEC / EN 61000-6-4,CE-RED
