Home EV Charger
Smart EV Charger
-
7.2kW / 11kW / 22kW
The Smart EV Charger supports both plug and socket outlet options to match user preferences. Designed to integrate with the X-ESS G4 solar+storage system, it ensures a unified energy ecosystem that maximizes performance and convenience.
-
Watch Video
Product Advantage
Capable of utilizing 100% renewable energy, the Smart EV Charger maximizes surplus green energy use in zero-export systems. Featuring smart dynamic load balancing, it supports efficient power distribution for sustainable electric vehicle charging.
Flexible Adaptability
Selectable plug or socket outlet
Easy indoor and outdoor installation
Supporting multiple communication protocols
High Efficiency
Capable of 100% green energy
Automatic switch between single and three phases
Maximizing surplus green energy utilization in a zero-export system
Assured Safety
Current leakage protection (30mA AC & 6mA DC)
Smart dynamic load balance control
Intelligent Design
Smart RFID management function
Smart APP remote control
Product Parameters
-
X1-EVC-7.2K-
AC NOMINAL INPUT
Phases/Lines Single phase Voltage 1 / N / PE, 230 V -
AC NOMINAL OUTPUT
Nominal output voltage 1 / N / PE, 230 V Power 7.2 kW -
INTERFACE
Wireless module Wi-Fi 2.4GHz -
GENERAL
Charging outlet Type P (Charging cable with plug) / Type S (Socket-outlet) Degree of protection IP65 Cooling method Natural cooling Application site Indoor / Outdoor Net weight 7 kg (for type S) / 10.5 kg (for type P) Dimensions (W x H x D) 249 × 370 × 155 mm (for type S) / 265 × 370 × 155 mm (for type P)
-
-
X3-EVC-11K
-
AC NOMINAL INPUT
Phases/Lines Three phase Voltage 3 / N / PE, 230 / 400 V -
AC NOMINAL OUTPUT
Nominal output voltage 3 / N / PE, 230 / 400 V Power 11 kW -
INTERFACE
Wireless module Wi-Fi 2.4GHz -
GENERAL
Charging outlet Type P (Charging cable with plug) / Type S (Socket-outlet) Degree of protection IP65 Cooling method Natural cooling Application site Indoor / Outdoor Net weight 7 kg (for type S) / 10.5 kg (for type P) Dimensions (W x H x D) 249 × 370 × 155 mm (for type S) / 265 × 370 × 155 mm (for type P)
-
-
X3-EVC-22K
-
AC NOMINAL INPUT
Phases/Lines Three phase Voltage 3/N/PE, 230 / 400 V -
AC NOMINAL OUTPUT
Nominal output voltage 3 / N / PE, 230 / 400 V Power 22 kW -
INTERFACE
Wireless module Wi-Fi 2.4GHz -
GENERAL
Charging outlet Type P (Charging cable with plug) / Type S (Socket-outlet) Degree of protection IP65 Cooling method Natural cooling Application site Indoor / Outdoor Net weight 7 kg (for type S) / 10.5 kg (for type P) Dimensions (W x H x D) 249 × 370 × 155 mm (for type S) / 265 × 370 × 155 mm (for type P)
-
Data Download
-
Datasheet
-
User Manual
-
Quick Installation Guide
-
Declaration
-
File nameLanguageFormatSizeLast updateddownload
